CISCO HWIC-2T ( CISCO SERIAL INTERFACE MODULE)

CISCO HWIC-2T ( CISCO SERIAL INTERFACE MODULE) Specification

Power Consumption
Not specified (low power consumption, draws from router)

IP Routing
Supported via host router

Usage & Applications
Industrial

Interface Type
Smart Serial

Operating Temperature
0C to 40C (32F to 104F)

Antenna
No

Weight
Approx. 90 g (0.2 lb)

Network Device
Yes

Dimension (L*W*H)
7.62 cm x 6.35 cm x 1.91 cm (3 in x 2.5 in x 0.75 in)

Features
Supports a wide range of serial WAN protocols (HDLC, Frame Relay, PPP, X.25, etc.), plug-and-play with compatible Cisco routers, manageable via Cisco IOS

Device Type
Networking

Remote Control
Yes

Port
2 x Smart Serial ports

Power Supply
Powered via host router

Number Of Ports/Pins
2 serial ports

Connectivity Type
Wireless or Wi-Fi

Cable Length
Depends on cable used, up to max serial spec

Storage Temperature
-40C to 70C (-40F to 158F)

Serial Protocols Supported
EIA/TIA-232, EIA/TIA-449, EIA/TIA-530, V.35, X.21, EIA-530A

Max Data Rate Per Port
Up to 8 Mbps (depending on interface/cable)

Compliance
RoHS, CE Mark, UL, CSA

Humidity Operating Range
10% to 85% non-condensing

Hot Swap Support
Yes (when installed in supported routers)

Module Type
HWIC-2T

Compatible Routers
Cisco 1800, 1900, 2800, 2900, 3800, 3900 Series Routers

Humidity Storage Range
5% to 95% non-condensing

LED Indicators
Yes (Link and Activity)

CISCO HWIC-2T ( CISCO SERIAL INTERFACE MODULE) Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
30 Pieces, Piece Per Month

Delivery Time
2-7 Days

Main Domestic Market
All India

About CISCO HWIC-2T ( CISCO SERIAL INTERFACE MODULE)

Cisco HWIC-2T is a 2-port serial WAN interface card, made for Cisco1800, 1900, 2800, 2900, 3800, and 3900 Series Integrated Services Routers. HWICs help customers enable applications such as WAN access, legacy protocol transport, console server, and dial access server. You can mix and match HWICs to tailor cost-effective solutions for common networking problems such as remote network management, external dial-modem access, low-density WAN aggregation, legacy protocol transport, and high-port-density support.

Reliable and Versatile Serial Connectivity

The HWIC-2T module offers reliable serial connectivity with two Smart Serial ports supporting multiple protocols and WAN interfaces. Its flexibility allows network administrators to deploy it in various scenarios, from industrial environments to service provider infrastructures. Hot swap support and compliance with environmental standards make installation and maintenance convenient for dynamic business needs.

Compatibility and Easy Management

This Cisco module integrates smoothly with several Cisco router series (1800, 1900, 2800, 2900, 3800, and 3900), enabling straightforward plug-and-play setup. Network management becomes simple with Cisco IOS, allowing IT teams to configure and troubleshoot easily, ensuring continuous and efficient network operation in demanding environments.

FAQ's of CISCO HWIC-2T ( CISCO SERIAL INTERFACE MODULE):

Q: How do I install the Cisco HWIC-2T module into my Cisco router?

A: To install the HWIC-2T, power off your compatible Cisco router, insert the module into the designated HWIC slot, and secure it. In supported routers, hot swapping is available-allowing installation or removal while the router is powered on. After installation, the module is managed via Cisco IOS.

Q: What routers are compatible with the Cisco HWIC-2T serial interface module?

A: The HWIC-2T module is compatible with Cisco 1800, 1900, 2800, 2900, 3800, and 3900 Series Routers, ensuring versatility for a range of enterprise and industrial network deployments.

Q: When should I consider using the HWIC-2T for my network setup?

A: Consider the HWIC-2T when you need reliable serial WAN links, require support for multiple serial protocols (EIA/TIA-232, V.35, X.21, etc.), or seek to expand connectivity in industrial or service provider environments. It's especially useful when high uptime and flexible installation are necessary.

Q: Where can I view the status of the HWIC-2T's ports?

A: The module features dedicated LED indicators for Link and Activity on each Smart Serial port. These visual cues help you quickly assess connection status and troubleshoot basic issues.

Q: What processes are involved in configuring the HWIC-2T for serial WAN protocols?

A: After physical installation, connect your serial cables and access your router's Cisco IOS interface. From there, configure the desired protocol (HDLC, Frame Relay, PPP, X.25, etc.) on each Smart Serial port to match your WAN requirements.

Q: How does the HWIC-2T benefit my network infrastructure?

A: The HWIC-2T boosts network flexibility by supporting a vast range of serial protocols and providing reliable, high-speed data links. Its hot swap capability, compact build, and low power draw make it an efficient choice for expanding WAN connectivity without disrupting network services.
