DELL R640XD

DELL R640XD
DELL R640XD
DELL R640XD

DELL R640XD Specification

  • Processor Type
  • Xeon
  • Type
  • Rack
  • Max Memory Capacity
  • GB/TB Gigabyte (GB)
  • Internal HDD
  • HDD/SSD Gigabyte (GB)
  • Processor Main Frequency
  • MHz Megahertz (MHZ)



About DELL R640XD

  • Processor

    Up to two 2nd Generation Intel Xeon Scalable processors with up to 28 cores per processor

    Operating System

    Canonical Ubuntu Server LTS
    Citrix Hypervisor
    Microsoft Windows Server with Hyper-V
    Red Hat Enterprise Linux
    SUSE Linux Enterprise Server
    VMware ESXi

    Accelerators

    Up to one single-width FPGA
    Up to three single-width GPU (NVIDIA T4)

    Memory

    DIMM Speed
    Up to 2933MT/s

    Memory Type
    RDIMM
    LRDIMM
    NVDIMM
    DCPMM (Intel Optane DC persistent memory)

    Memory Module Slots
    24 DDR4 DIMM slots (12 NVDIMM or 12 DCPMM only)
    Supports registered ECC DDR4 DIMMs only

    Maximum RAM
    RDIMM 1.53TB
    LRDIMM 3TB
    NVDIMM 192GB
    DCPMM 6.14TB (7.68TB with LRDIMM)

    Storage

    Front Bays
    Up to 10 x 2.5 with up to 8 NVMe, SAS/SATA/SSD/NVMe, max 76.8TB
    Up to 10 NVMe, max 64TB
    Up to 4 x 3.5 SAS/SATA, max 56TB

    Rear Bays
    Up to 2 x 2.5 SAS/SATA/SSD/NVMe, max 15.36TB

    Storage Controllers

    Internal Controllers:
    PERC H330, H730P, H740P, HBA330

    External Controllers
    12Gbps SAS HBA

    Software RAID
    S140

    Internal Boot
    Boot Optimized Storage Subsystem (BOSS):
    HWRAID 2 x M.2 SSDs 240GB, 480 GB

    Internal Dual SD Module

    Security

    Cryptographically signed firmware
    Secure Boot
    Secure Erase
    Silicon Root of Trust
    System Lockdown (requires OpenManage Enterprise)
    TPM 1.2/2.0, TCM 2.0 optional

    Management

    Embedded / At-the-Server
    iDRAC9
    iDRAC RESTful API with Redfish
    iDRAC Direct
    Quick Sync 2 BLE/wireless module

    Consoles
    OpenManage Enterprise
    OpenManage Power Center

    Mobility
    OpenManage Mobile

    Tools
    Dell RACADM CLI
    Dell Repository Manager
    Dell System Update
    Dell Server Update Utility
    Dell Update Catalogs
    iDRAC Service Module
    IPMI Tool
    OpenManage Server Administrator
    OpenManage Storage Services

    OpenManage Integrations
    BMC Truesight
    Microsoft System Center
    RedHat Ansible Modules
    VMware vCenter

    OpenManage Connections
    IBM Tivoli Netcool/OMNIbus
    IBM Tivoli Network Manager IP Edition
    Micro Focus Operations Manager I
    Nagios Core
    Nagios XI

    Power Supplies

    495W Platinum
    750W Platinum
    750W 240HVDC Platinum*
    1100W 48VDC
    1100W Platinum
    1100W 380HVDC Platinum*
    1600W Platinum
    750W Titanium
    Hot plug power supplies with full redundancy option
    Up to 8 hot plugs fans with full redundancy

    Ports

    Network Options
    4 x 1GbE
    2 x 10GbE + 2 x 1GbE
    4 x 10GbE
    2 x 25GbE

    Front Ports
    1 x Dedicated iDRAC direct USB
    1 x USB 2.0
    1 x USB 3.0 (optional)
    1 x Video

    Rear Ports
    1 x Dedicated iDRAC network port
    1 x Serial
    2 x USB 3.0
    1 x Video

    Slots

    PCIe
    3 x Gen3 slots (all x16)

    Video Card
    1 x VGA

    Bezel

    Optional LCD bezel or security bezel

    Form Factor

    1U Rack Server

    Dimensions & Weight

    Height
    42.8mm (1.69)

    Width*
    482.0mm (18.98")

    Depth*
    808.5mm (31.8")

    Weight
    21.9kg (48.3 lbs.)

    Rack Support

    ReadyRails sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for threaded hole racks).

    Recommended Support

    Choose Dell ProSupport Plus for critical systems or Dell ProSupport for premium hardware and software support for your PowerEdge solution. Consulting and deployment offerings are also available. Contact your Dell representative today for more information. Availability and terms of Dell Services vary by region.

    Regulatory

    Product Safety and Environmental Datasheets
    Dell Regulatory Compliance Home Page
    Dell and the Environment
